OPS-IH510DS-OC4N
OPS Computer Based on Intel Comet Lake-S/ Intel Rocket Lake-S Processors
Key Features
- Supports Intel H510 chipset, 10/11th Generation Intel Core Processors
- Dual-channel DDR4 up to 32GB
- Front panel DP1.4a + HDMI1.4
- Supports UHD, H.264 and H.265 decoding
- 1*Type-C, 2*USB3.0, 4*USB2.0, 1*COM-RS232
- Applications: White board, all-in-one pc, digital signage, intelligent retail, etc.
| Processor | CPU | Intel Comet Lake-S, Rocket Lake-S Processors |
| Chipset | Intel H510 Chipset | |
| BIOS | AMI EFI 128 Mbit | |
| Memory | Type | 2*DDR4-3200MHz SO-DIMMs |
| Max. Capacity | 32GB | |
| Display | GPU | Intel UHD Graphics 620/610 (based on CPU) |
| Front Panel |
1*DP1.4a, Max. 3840 x 2160@60Hz 1*HDMI1.4, Max. 3840 x 2160@30Hz |
|
| JAE |
1*DP1.4a, Max. 3840 x 2160@60Hz 1*HDMI2.0, Max. 3840 x 2160@60Hz |
|
| Audio | Controller | Realtek ALC662-VD0 |
| Interface | Audio out + Mic in | |
| Ethernet | Controller | Realtek RTL8111H, Gigabit Ethernet, Wake on LAN support |
| Storage | 2.5" SATA | 1*2.5" SATA HDD/SSD |
| M.2 | 1*M.2 2280, SATA/PCIe 4X SSD | |
| Rear Panel | DP1.4a | 1 |
| HDMI2.0 | 1 | |
| Audio | Audio out + Mic in | |
| USB2.0 | 4 | |
| USB3.0 | 2 | |
| Type-C | 1 x USB3.0 | |
| LAN | 1 | |
| COM | 1 | |
| Expansion | M.2 | 1*M.2 2230 with Wi-Fi/BT module support |
| JAE | JAE TX25 80Pin | |
| OS | Windows 10 64bit, Linux | |
| Functions | Watchdog, Auto Power On | |
| Power | Power Type | DC IN |
| Adapter | 12V-19V | |
| Cooling | Fan | |
| Dimension | Construction | Metal |
| Mounting | Yes | |
| W*H*D | 180*195*42mm | |
| Environment | Operating Temp. | 0°C to 40°C at 0.7m/s air flow |
| Storage Temp. | -20°C to 60°C | |
| Relative Humidity | 95% at 40°C, non-condensing |
